Nikon Eyepiece 16-48x/20-60x (SEP20-60) For PROSTAFF 5 Spotting Scopes
Dedicated eyepiece for use with specific Nikon PROSTAFF 5 Fieldscope. Designed for digiscoping with certain COOLPIX cameras.
Discover more of the Nikon Optics range here.
Key Features:
- Bayonet mount
- Lock for easy attachment and release
- Fully multi-layer coated
- Water resistance
- Long eye relief
- New Turn-slide eyecups
Specification
|
*1) Calculated based on ISO14133. *2) Without caps. Specifications and images are subject to change without notice. |
|
| Magnification [x] (with PROSTAFF 5 Fieldscope 82) | 16-48 |
| Magnification [x] (with PROSTAFF 5 Fieldscope 60) | 20-60 |
| Real Field of View [degree] (with PROSTAFF 5 Fieldscope 82) *1 | 2.6 |
| Real Field of View [degree] (with PROSTAFF 5 Fieldscope 60) *1 | 2.1 |
| Apparent Field of View [degree] *1 | 39.9 |
| Exit Pupil [mm] (with PROSTAFF 5 Fieldscope 82) | 3.8 |
| Exit Pupil [mm] (with PROSTAFF 5 Fieldscope 60) | 4.1 |
| Brightness (with PROSTAFF 5 Fieldscope 82) | 14.4 |
| Brightness (with PROSTAFF 5 Fieldscope 60) | 16.8 |
| Eye Relief [mm] | 16.9 |
| Field of View at 1000m [m] (with PROSTAFF 5 Fieldscope 82) | 33 |
| Field of View at 1000m [m] (with PROSTAFF 5 Fieldscope 60) | 42 |
| Coating | Fully multilayer coated |
| Length [mm] *2 | 74 |
| Outside Diameter [mm] *2 | 63 |
| Waterproofness | Filled with nitrogen gas. Up to 2m under water for 10 min. The joint between the body and eyepiece is water-resistant. |
| Mount | Bayonet |
| Eyecup | New Turn-Slide |
| Compatibility with FSB series (Digiscoping) | Yes |
