| SENSOR SECTION |
SENSOR FOR MAIN CAMERA |
Image Sensor |
1/2.5-type BSI MOS Sensor |
| Total Pixels |
8.57 megapixels |
| Effective Pixels [Motion Image] |
4K: 8.29 megapixels [16:9], Full-HD: 6.17 megapixels [16:9] (Level Shot Function OFF or Normal) |
| Effective Pixels [Still Image] |
8.29 megapixels [16:9] 6.22 megapixels [4:3] |
| SENSOR FOR SUB CAMERA |
Image Sensor |
– |
| Total Pixels |
– |
| LENS SECTION |
LENS FOR MAIN CAMERA |
F Value |
F1.8 (WIDE) / F4.0 (TELE) |
| Optical Zoom |
24x |
| Focal Length |
4.12 – 98.9 mm (Optical Zoom：24x) |
| 35 mm Film Camera Equivalent [Motion Image (16:9)] |
4K/Full-HD 24p: 25 – 600 mm*, Full-HD 60p/60i/30p: 28.9 – 693.7 mm* * 16:9, Level Shot Function OFF or Normal |
| 35 mm Film Camera Equivalent [Still Image] |
25.0mm – 600mm (16：9) / 30.6mm – 734.4mm (4：3) |
| Filter Diameter |
62 mm |
| Lens Brand |
Leica Dicomar Lens |
| LENS FOR SUB CAMERA |
F Value |
– |
| Focal Length |
– |
| 35 mm Film Camera Equivalent [Motion Image] |
– |
| CAMERA SECTION |
Standard Illumination |
1400 lx |
| Minimum Illumination |
1.5 lx (Scene Mode Low Light 1/30), 0.5 lx (Night Mode (Color)), 0 lx (Night Mode (IR)) |
| Focus |
Auto / Manual |
| Zoom |
Intelligent Zoom OFF |
24x |
| Intelligent Zoom ON |
4K: 32x, Full-HD: 48x |
| Digital Zoom |
70x / 1500x (The maximum value of zoom magnification can be set in two patterns) |
| White Balance |
Auto / White Set / Sunny / Cloudy / Indoor1 / Indoor2 / Variable |
| Shutter Speed |
Motion Image |
Auto Slow Shutter ON : 1/30 – 1/8000 (60p / 60i / 30p), 1/24 – 1/8000 (24p) Auto Slow Shutter OFF: 1/60 – 1/8000 (60p / 60i / 30p), 1/48 – 1/8000 (24p) |
| Still Image |
1/2 – 1/2000 |
| Iris |
Auto / Manual |
| Image Stabilizer |
5-axis HYBRID O.I.S.+ with Active Mode, O.I.S. Lock, Level Shot Function (Strong mode: 2K only), Ball O.I.S., Adaptive O.I.S. |
| Active Cotnrast |
Yes |
| HDR Movie (Except 4K Mode) |
Yes |
| Creative Control (Except 4K Mode) |
Miniature Effect, Silent Movie, 8mm Movie, Time Lapse Rec |
| RECORDING SECTION |
Recording Media |
SD/SDHC/SDXC Memory Card |
| Recording Format |
[AVCHD] AVCHD Progressive [MP4] MP4
MPEG-4 AVC/H.264 |
| Recording/ Playback Mode |
AVCHD |
1080/60p (28Mbps / VBR), (1920 x 1080/60p) PH (24Mbps / VBR), (1920 x 1080/60i) HA (17Mbps / VBR), (1920 x 1080/60i) HG (13Mbps / VBR), (1920 x 1080/60i) HE (5Mbps / VBR), (1920 x 1080/60i)
|
| MP4 |
2160p/30p(72M) (72Mbps / VBR), (3840 x 2160) 2160p/24p(72M) (72Mbps / VBR), (3840 x 2160) 1080p/60p(50M) (50Mbps / VBR), (1920 x 1080) 1080p/60p(28M) (28Mbps / VBR), (1920 x 1080) 1080p/24p(50M) (50Mbps / VBR), (1920 x 1080) 720p/30p(9M) (9Mbps / VBR), (1280 x 720)
|
| iFrame |
– |
| Actual Recordable Time with Supplied Battery (LCD OFF) |
Approx. 45 min (4K MP4) Approx. 50 min (60p mode) Approx. 50 min (PH mode) Approx. 50 min (HA mode) Approx. 50 min (HG mode) Approx. 50 min (HE mode) Approx. 50 min (2160p/24p) Approx. 1 h 0 min (1080p/24p) Approx. 50 min (MP4 50M) Approx. 50 min (MP4 28M) Approx. 1 h 0 min (MP4 720p) |
| Thumbnail Display |
6 thumbnails/page, 1 thumbnail/page |
| Audio Recording System |
AVCHD: Dolby Audio (5.1ch / 2ch) MP4: AAC (2ch) |
| Microphone |
5.1ch Surround, Zoom, Focus and Stereo Microphone |
| Speaker |
Dynamic type |
| STILL IMAGE SECTION |
Recording Format |
JPEG (DCF/Exif2.2) |
| Recording Image Size |
Still Image |
[16:9] 25.9megapixels (6784 x 3816), 14 megapixels (4992 x 2808), 2.1 megapixels (1920 x 1080) [4:3] 20.4 megapixels (5216 x 3912), 10.9 megapixels (3808 x 2856), 0.3 megapixels (640 x 480) |
| Simultaneous Recording |
Full-HD only: [16:9] 14.0 megapixels (4992 x 2808), 2.1 megapixels (1920 x 1080) |
| Flash |
– |
| GENERAL SECTION |
Power Supply |
3.6V (Battery) / 5.0V (AC Adaptor) |
| Power Consumption |
TBD |
| Dimensions (W x H x D) |
Approx. 69 x 77 x 167 mm (2.717 x 3.032 x 6.575 inch) |
| Weight (w/o battery and SD card) |
Approx. 450 g (0.992 lb) |
| LCD Monitor |
3.0-inch Wide LCD monitor (460,800 dots) |
| Touch Panel |
Yes |
| View Finder |
0.24-inch Wide EVF (1.555.200 dots equivalent) |
| Manual Ring / Dial |
Yes (Ring) |
| Interface |
AV |
– |
| HDMI |
Yes (micro) |
| Microphones (stereo mini) |
Yes |
| LINE-IN (stereo mini) |
Yes (Shared with mic jack) |
| Headphone (stereo mini) |
Yes |
| USB |
2.0 Hi-Speed |
| USB Charge |
Yes |
| LED Video Light |
– |
| Accessory Shoe |
Yes (cold) |
| Lens Cover |
Yes (Auto) |
| On-Screen Display Language |
EB |
| Wi-Fi |
Standard |
IEEE 802.11b/g/n |
| Frequency |
2.4GHz band |
| NFC |
– |
| STANDARD ACCESSORY |
AC Adaptor |
Yes |
| AC Cable |
– |
| DC Cable |
Yes (USB Type) |
| Rechargeable Battery Pack |
Yes (1,940mAh) |
| Battery Charger |
– |
| IR Remote |
– |
| HDMI Cable |
Yes (micro) |
| AV Multi Cable |
– |
| AV Cable |
– |
| Shoe adaptor |
– (Built-in) |
| Lens Hood |
Yes |
| USB Cable |
Yes |
| Editing Software |
HD Writer AE 5.4 (Download) |
